Jenis pembayaran:L/C,T/T,D/P,D/A,Paypal
Inkoterm:CFR,FOB,CIF
Min. Memesan:1
Transportasi:Ocean,Land,Air
$0.1-1 /
Merek: HY atau OEM
Tempat Asal: Cina
Material: Pvc
Processing Service: Moulding
Color: Transparent
Baik: PIPA TERMOPLASTIK
Water Absorption: ＜0.01%
Contraction Percentage: 1.0%~2.5%
Kekuatan Tarik: （30 ~ 40） MPa
Pressure: 1.6Mpa
Temperature: -15 to 55 Degree Celsius
Transportasi: Ocean,Land,Air
Jenis pembayaran: L/C,T/T,D/P,D/A,Paypal
Inkoterm: CFR,FOB,CIF
Serikat PVC Bening kami yang berkualitas tinggi, termasuk ukuran serikat 1 pvc yang ringkas, adalah jenis pemasangan serikat pvc praktis yang dirancang untuk sistem pipa transparan. Dibuat dari PVC sebening kristal, mereka memungkinkan inspeksi visual yang cepat pada sambungan sekaligus memastikan sambungan anti bocor dan mudah dibongkar. Tahan korosi dan kompatibel dengan pipa PVC standar, sambungan ini menyederhanakan pemeliharaan dan perbaikan pengaturan akuarium, saluran cairan laboratorium, dan proyek pipa perumahan.
| HuiYa PVC fittings series | ||
| DIN | ANSI | JIS |
| PVC PN10 | PVC SCH40 | |
| PVC PN16 | PVC SCH80 | |
| Key Word: | Clear PVC Union DIN PN16 | |||
| Connect Type: | Cement-Glue-Socket | |||
| Brand: | HUIYA or OEM | |||
| Material: | PVC(PVC-U) | |||
| Specifications: | Size(dimensions): | DN15-20-25-32-40-50-65-80-100-125-150-200-250-300-350-400 | ||
| 20-25-32-40-50-63-75-90-110-125-140-160-200-225-280-315-355-400mm | ||||
| Color: | Transparent | |||
| Standard: | ISO , ISO4422, , DIN8063,GB/T 4219.2 | |||
| Working pressure: | PN16(1.6Mpa) | |||
| Working temperature: | -15 to 55 Degree Celsius | |||
| Production Process: | Mold Injected | |||
| Packing: | Cartons | |||
| Advantage: | 1.100% virgin PVC material | |||
| 2.Environmentally friendly material, 100% no lead, zinc and other metals, water quality unaffected,harmless to the body | ||||
| 3.Strictly produced according to ISO standard | ||||
| 4.Long lifetime | ||||
| 5.The pressure resistance reaches 1.6 MPa, Good chemicals and drugs resistance | ||||
| Application: | Connected with PVC-U pipes for portable water supply，also can be used for corrosive medium transportation in chemical industry and other fields | |||
| HS Code: | 391740 | |||
| Certificate: | SGS | |||
| Brief Introduction: | HuiYa Plastic Co., Ltd is a professional supplier of UPVC-CPVC-PE-PPR Pipes, pipe fittings, valves,Upvc Pipe Fittings And Valves,Pph Pipe Fittings And Valves. Plastic piping systems such as pipes, fittings and valves is widely used in water supply, chemical industry, water treatment, environmental protection, pharmaceutical area etc. | |||
| We insist in the principal of Quality First, Clients First". Your satisfaction is our eternal pursuit. With high-class raw material, strict quality control in both the workshop and laboratory with various professional testing equipment, HuiYa Plastic ensures that every single product meets the corresponding inspection standard. | ||||
Sederhanakan pemeliharaan saluran pipa Anda dengan UPVC Clear Union kami yang bermutu tinggi. Didesain agar mudah dibongkar, Serikat PVC Bening Jadwal 40 ini memungkinkan Anda memeriksa, membersihkan, atau memodifikasi sistem Anda tanpa pemotongan apa pun. Bodi sebening kristal menyediakan pemantauan visual 360 derajat, sehingga memudahkan verifikasi kondisi aliran dan integritas segel O-ring. Sebagai solusi tahan korosi dan bertekanan, penyatuan transparan kami sempurna untuk pemrosesan kimia, penyaringan laboratorium, dan sistem air dengan kemurnian tinggi.
